12*22mm DMX512 RGBW Side View LED Neon strip DC24V

Description

Description

· 12x22 arc surface luminous neon light bar, can bend left and right;
· Light source: highlights lamp beads;
· Control method: Differential parallel dmx512 (1990) signal protocol,
 built -in anti -interference module,
· Strengthen anti -interference ability;
· Craft material: high -light transmission and environmental -friendly
 silicone material, good flexibility of silicone material;
· Optical design: Unique optical light structure design, uniform
 light on the surface, no shadow,
· The light -free spots, the light is very soft;
· Exterior design: simple and fashionable, exquisite and unique
 brings better lighting performance to indoor/outside applications;
· Product certification: UL, CE, RoHS;



Share to

Facebook Twitter

Specification

Product Parameter

    PN
    N012060CC4DC0 (N1222)Arc
   N012060CC4DE1 (N1222)Arc
    Voltage
    DC24V
   DC24V
    LED Type
    SMD5050
   SMD5050
    LED Qty
    60LEDs/m
   60LEDs/m
    Color
    RGBW
   RGBW
    Lumen
    R:60 G:138 B:40 W:197lm/m
   R:60 G:138 B:40 W:197lm/m
    Dimension
    5000*12*22mm
   5000*12*22mm
    Pixel
    10Pixel/m TM512AC
   10Pixel/m Hi512
    Power
    19.2W/m
   19.2W/m
    Max Length
    15m   15m
    O.T    -25℃ ~ 60℃    -25℃ ~ 60℃
Remarks:
1. The above parameters are tested based on 1M standard products;
2. The luminous flux is allowed to have an error range of ±10%;
3. The above parameters are typical values;
4. The brightness with in 15M is consistent even if one end is powered;
5. Subject to change without prior notice.
6. Length tolerance applies. Actual product dimensions may vary



Note: Length tolerance applies. Actual product dimensions may vary
