Description
This is side emitting Neon strip, An-ti fire silicon material with diffused color on top side.
Inside part is the SK6812 addressable RGBW LED flex, 60pcs of LEDs and Pixels per meter.
Standard size: 5 meters in a reel, but each LED can be cut and you can customize the size/length.
Without light shadow, and IP65 rated.
It has multi CCT of White, Warm white around 3000K, Nature white around 4000K
|
PN |
N010060CA4SA1 |
|
Voltage |
DC5V |
|
Material |
Silicon |
| LED Quantity |
60LEDs/m |
|
Luminance |
R:83 G:202 B:68 W:237/WW:295 |
| CCT | WW:2800-3200K / W:5000-5500K |
|
Dimension |
5000*10*20mm |
| Cutting unit | 16.6mm |
|
Power |
14W/m |
|
IP |
IP65 |
| O.T | -25℃ ~ 60℃ |
Remarks:
1. The above parameters are tested based on 1M standard products;
2. The luminous flux is allowed to have an error range of ±10%;
3. The above parameters are typical values;
4. The brightness with in 15M is consistent even if one end is powered;
5. Subject to change without prior notice.
6. Length tolerance applies. Actual product dimensions may vary
Dimension (unit:mm)
Note: Length tolerance applies. Actual product dimensions may vary
Accessory
