480LEDs/m COB single color led strip DC12/24V

Application:

1. Night Club
2. KTV singing club
3. Dance floor
4. TV Show Back gound
5. Stage,Disco Club
6. Outdoor building,fridge

Share to

Specification

Product Parameter

    PN
    S008480ZB1LZ    |    S008480ZC1LZ
    Voltage
    DC12V                 |    DC24V
    SMD Type
    COB
    LED Quantity     480 leds/m
    CCT
    3000K  4000K  6000K
    Dimension
    5000*8 MM
    Lumens/m
    1100 LM
    PCB Color     White
    Power
    10 W/M
    CRI
    92 RA
    O.T     -25℃ ~ 45℃

Description

What is a COB LED Strip Light ? Compared to the SMD 2835: 1 chip on board, or 5050: 3 chips

on board, a COB(Chip On Board) LED light has multiple chips on the same PCB (Printed Circuit

Board),which make the emitting units unprecedentedly close to each other, and create super

even lighting performance The Highlights of COB: Lower power, higher light efficiency
(110LM/W),higher CRI(85+). 180 degrees beam angle design for 50% wider lighting,multiple

chips on board for uniform illumination,NO MORE worries about dark spot!


Dimension (unit:mm)

320 LEDs/m COB LED Strip

IP Rate
