6mm Wide 2835 RGB flex led strip 120LEDs/m DC24V

Application:

1. Hotels,restaurants,nights clubs,

2. Shopping malls,various shops,

3. Coffee/wine bars, furniture light

4. Cinemas,beauty centers,
5. Coffee/wine bars, furniture light.

Email: inquiry@ipixelleds.com

Share to

Specification

Product Parameter

    PN
     S006120BC3PZ
    Voltage
     DC24V
    LED Type
     SMD 2835 RGB
    LED Quantity     120leds/m
    Color      RGB
    Dimension
     5000*6mm
    Cutting unit
     50mm
    Wavelength
     R:620-625 G:520-525 B:460-465nm
    Luminance/M
    Ｒ:100 Ｇ:240 Ｂ:36LM
    Material     FPC
    Power
     15 W/M
    Protocol
     PWM
    O.T     -25℃ ~ 60℃

Description

This led strip with 120pcs 2835 RGB LED chips

You can use PWM controller to control it

The input voltage is DC24V Flexible PCB, the FPCB color is white

The FPCB width is 6mm, 1 + 2 Oz copper

Standard 5M/roll, length can be customized

Dimension (unit:mm)

SMD 4040 RGB LED Strip 120 LED/M

IP Rate

SMD 4040 RGB LED Strip 120 LED/M
