RGB COB led strip 840LEDs/m

Application:

1. Night Club
2. KTV singing club
3. Dance floor
4. TV Show Back gound
5. Stage,Disco Club
6. Outdoor building,fridge


Share to

Specification

Product Parameter

    PN
    S010840ZC3PZ
    Voltage
    DC24V
    SMD Type
    COB
    LED Quantity     840 LEDs/m
    View Color
    RGB
    Dimension
    5000*10mm
    Lumens/m
    R:135LM G:271LM B:72LM
    PCB Color     White
    Power
    16 W/M
    Minimum Cutting Length
     25mm
    IP Rate     IP20/IP64/IP65

Description

1. This PWM RGB COB led strip is very soft and can be bent at will.
2. It has three basic colors, red, green and blue and the color can be adjusted by controller.
3. It uses SMD flip chip, which is highly integrated, 840LEDs/m
4. High brightness, uniform luminescence and no spot.
5. Every 25mm can be cut, and thicker PCB with 1+2 ounce copper thickness.
6. It is suitable for dark grooves, parks, squares, buildings, architectural lighting...


Dimension (unit:mm)

RGB COB led strip 840LEDs/m

IP Rate


RGB COB led strip 840LEDs/m
