-High efficiency, remarkable energy saving effect
-Double layer PCB, balancing voltage drop, heat
dissipation and flexibility.
-Chip longitudinal distribution, high reliability;
-Standard 5M/roll, length can be customized
|
PN |
S010560ZC4SC5 |
|
Voltage |
DC24V |
|
Power |
16W/m |
|
SMD Type |
COB |
| LED Quantity |
560LEDs/m |
|
Dimension |
5000*10mm |
|
Cutting length |
100mm |
|
Lumens(lm/m) |
30 |
|
Wavelength |
R:615-630 G:520-535 B:450-460nm |
| Control | SPI-WS2814 |
| O.T | -25℃ ~ 60℃ |
Dimension (unit:mm)
