Germany Stage Decoration – 12V Dual-Signal Addressable RGB LED Strip 60LEDs/m (S010060CB3SB7)
Germany Stage Decoration – 12V Dual-Signal Addressable RGB LED Strip 60LEDs/m (S010060CB3SB7)
S010060CB3SB7 is designed for stage decoration, retail ambience and linear pixel lighting effects. Using SMD5050 RGB LEDs at 60 pixels per meter, it enables chasing, flowing, gradient and segmented color effects via WS2815/HC2815 control systems.
- Dual-signal data + breakpoint resume: redundancy design keeps downstream pixels operating even if a single LED fails or is removed, improving installation reliability.
- DC12V input: reduced voltage drop compared with 5V pixel strips, suitable for medium-length runs.
- Fine cutting: cuttable every LED (approx. 16.66mm), easy to fit exact structure lengths.
- Mechanical & wiring: 10mm white/black PCB, 120° beam angle, standard 4-pin JST-SM connector; IP options IP20 / IP64 / IP65.
- Typical specs (IP20): 9W/m; wavelengths R 615–630nm / G 520–535nm / B 450–460nm; operating temp -25~60°C.Customization is available for length, cable/connector, and IP protection process, plus matching controller & power supply recommendations.
