The FUT028 is designed for common-anode, constant-voltage RGBW LED strips and other five-wire RGBW lighting products.
2.4GHz RGBW Touch Controller – FUT028
2.4GHz RGBW Touch Controller – FUT028
Four-channel RGBW controller with touch color selection, independent white adjustment, automatic synchronization and RF signal forwarding.
Product Specification Table
| Parameter | Specification |
|---|---|
| Product Name | 2.4GHz RF RGBW Touch Controller |
| Model No | FUT028 / FUT028000CC0 |
| Controller Type | Constant-Voltage PWM LED Controller |
| Compatible LED Type | RGBW LED Strips, Light Bars and Modules |
| Output Configuration | RGB + White |
| Wiring Type | Common Anode |
| Input Voltage | DC 12–24V |
| Output Channels | 4 Channels |
| Maximum Load Current | 6A per Channel |
| Control Method | 2.4GHz RF Touch Remote |
| Remote Frequency | 2400–2483.5MHz |
| Modulation | GFSK |
| Remote Distance | Approx. 20–30m |
| Color Control | Touch Color Ring |
| White-Light Control | Independent White Channel |
| Dynamic Modes | 9 Modes |
| Brightness Adjustment | Supported |
| Speed Adjustment | Supported in Dynamic Modes |
| Power-Off Memory | Supported |
| Automatic Synchronization | Supported |
| Signal Forwarding | Supported |
| Receiver Standby Power | ≤0.5W |
| Receiver Size | 85 × 45 × 22mm |
| Remote Voltage | 3V |
| Remote Battery | 2 × AAA Batteries |
| Remote Standby Current | <20μA |
| Remote Transmit Power | 6dBm |
| Remote Size | 110 × 52 × 20mm |
| Installation Environment | Dry Indoor Location |
FAQ
No. This controller provides RGB plus one independent white channel. RGB+CCT strips require a five-channel controller with separate warm-white and cool-white outputs.
Yes. A 12V or 24V constant-voltage power supply is required. The power-supply voltage must match the LED product voltage.
Yes. One remote can be paired with multiple receivers. Multiple controllers can also forward the RF command to extend the control coverage.
